- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com.au
- Brand Name
- APC by Schneider Electric
- Product Line
- Smart-UPS
- Product Type
- Double Conversion Online UPS
- Technical Information
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 6 x IEC 60320 C13
- 2 x IEC 60320 C19
- Power Description
- Load Capacity (VA)
- 3 kVA
- Load Capacity (Watt)
- 2.70 kW
- Input Voltage
- 230 V AC
- Input Voltage Range
- 160 V AC - 275 V AC
- Output Voltage
- 220 V AC
- 230 V AC
- Input Frequency
- 70 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Management
- Network Management
- Network Card
- Alarm
- Alarm
- Interfaces/Ports
- USB
- Yes
- EPO Port
- Yes
- Battery Information
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Size
- 48V
- Battery Energy
- 10368 kJ
- Backup/Run Time (Full Load)
- 48 Minute
- Backup/Run Time (Half Load)
- 1.55 Hour
- Battery Life
- 10 Year
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Storage Temperature
- -20°C - 50°C
- Maximum Operating Elevation
- 10 km
- Maximum Storage Elevation
- 15.24 km
- Operating Humidity
- 0% - 95%
- Storage Relative Humidity
- 0% - 95%
- Sound Emission (A-Weighted)
- 50 dB(A)
- Thermal Dissipation
- 317 BTU/h
- Physical Characteristics
- Color Family
- Multicolor
- Product Color
- Blue
- Height
- 171 mm
- Width
- 432 mm
- Depth
- 639 mm
- Rack Height
- 4U
- Form Factor
- Rack-mountable
- Weight (Approximate)
- 44.50 kg
