- General Information
- Manufacturer
- ASRock, Inc
- Manufacturer Website Address
- http://www.asrock.com
- Brand Name
- ASRock
- Product Type
- Desktop Motherboard
B150M Pro4/D3
- ASRock Super Alloy
- Supports 6th Generation Intel® Core™ Processors (Socket 1151)
- Supports Dual Channel DDR3 1866(OC)
- 2 PCIe 3.0 x16, 1 PCIe 3.0 x1, 1 PCI
- AMD Quad CrossFireX™, CrossFireX™
- Graphics Output Options: DVI-D, HDMI
- 7.1 CH HD Audio (Realtek ALC892 Audio Codec), ELNA Audio Caps
- 6 SATA3
- 6 USB 3.0 (2*Front, 4*Rear)
- Supports Full Spike Protection, ASRock Live Update & APP Shop
- Processor & Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- B150
- Total Processor Supported
- 1
- Processor Socket
- Socket H4 LGA-1151
- Processor Supported
- Core i7
- Core i5
- Core i3
- Pentium
- Celeron
- Multi GPU Supported
- CrossFireX
- Memory
- Number of Memory Slots
- 4
- Memory Form Factor
- DIMM
- UDIMM
- Maximum Memory Supported
- 64 GB
- Memory Technology
- DDR3 SDRAM
- DDR3L SDRAM
- Memory Speed Supported
- 1866 MHz
- 1600 MHz
- 1333 MHz
- 1066 MHz
- I/O Controller
- Controller Type
- Serial ATA/600
- Video
- Onboard Video
- CPU Dependent Video
- Graphics Controller Manufacturer
- Intel
- Audio
- Audio Channels
- 7.1
- Network & Communication
- Gigabit Ethernet
- Yes
- I/O Expansions
- Total Number of Expansion Slots
- 4.0
- Total Number of PCI Express Slots
- 3
- Number of PCI Express x1 Slots
- 1
- Number of PCI Express x16 Slots
- 2
- Interfaces/Ports
- Total Number of USB Ports
- 6
- Number of USB 3.0 Ports
- 4
- VGA
- Yes
- HDMI
- Yes
- DVI
- Yes
- Onboard Interfaces
- Number of SATA Interfaces
- 6
- Total Number of Onboard USB Ports
- 6
- Number of Onboard USB 3.0 Ports
- 2
- Physical Characteristics
- Form Factor
- Micro ATX
- Miscellaneous
- Environmentally Friendly
- Yes
